RFID Card UHF NXP UCODE® DNA

Blank or customized printing RFID card with a choice of dimensions available, or RFID label by request.

Contact sales

Description

The UCODE® DNA IC is targeting secure asset tagging applications that require both cryptography authentication checks and long reading range.

UCODE® DNA offers significantly better security to perform cryptographic authentication by an AES coprocessor, with two 128-bit AES keys stored.

The difference between UCODE® DNA, UCODE® DNA Track and UCODE® DNA City is mainly the size of memory. Besides, UCODE® DNA got two 128-bit AES keys stored, where only one key provided for UCODE® DNA Track and UCODE® DNA City.



Features

Frequency Band

UHF 860~960 MHz

Chip Type

NXP UCODE® DNA

International Standard

ISO/IEC 29167-10, EPCglobal Gen2v2

EPC memory

224 bits

User Memory

Up to 3 kbit

Data Transfer

32 bits/1.5 milliseconds

Specifications

Physical Specifications

Material:
Black Core PVC, White Core PVC, White Core PET (WEEE Directive✓)
White Core ABS (WEEE Directive✓), Wooden (WEEE Directive✓)
Dimensions: 85.6×54×0.88mm | 3.37¨×2.125¨
Net Weight: About 5.8 g
Surface Treatment: Glossy, Matte or Frosted
Personalized Printing (NA for Wooden Cards): Thermal Transfer / Dye Sublimation
Customization Options (NA for Wooden Cards): Pre-Printing, Barcode Printing, Embossing, Holograms, Signature Panels, UV Printing, Hot Stamping, Punch Holes

Environmental Spec

Operating Limits: 0°C ~ 50°C, 20% ~ 90% RH
Storage Limits: 18°C ~ 28°C, 20% ~ 90% RH
Care Tips:
1. Avoid excessive bending.
2. Keep away from water.
3. Store in cool and dry place.
Cleaning Tips:
1. Use a soft, dry cloth.
2. Avoid harsh chemicals or abrasive cleaners.
3. Remove stains immediately.

Chip Characteristics

Chip Manufacturer: NXP®
Chip Type: UCODE® DNA
User Memory: 3 kbits
EPC Memory: 224 bits
TID: 96 bits
Write Endurance: 100,000 cycles
Data Retention: 20 years
Read Sensitivity: -19 dBm
AES Authentication Sensitivity: -18 dBm
Write Sensitivity: -11 dBm
Kill Password: 32 bits
Access Password: 32 bits
Cryptography: AES-128

Technical Parameters

Operating Frequency: 860~960 MHz
Support Protocols: ISO/IEC 29167-10, EPCglobal Gen2v2
Encoding Speed: 32 bits per 1.5 milliseconds

Packaging

Packing Format: Single pieces, piece by piece
Packing Quantity: 200 pcs/case, G.W.: 1.26 kg
Packing Method: 1000 pcs or 2000 pcs/carton
Carton Dimension:
1000 pcs: 23×20×17 cm (G.W.: 6.3 KG)
2000 pcs: 48×23×14 cm (G.W.: 12.6 KG)
