The UHF RFID Antenna 5dBi features a high front-to-back ratio, narrow sidelobes, and a 5dBi gain, ensuring stable performance. It enables accurate and rapid multi-label reading and writing, with a moderate read-write distance. Despite its small size, lightweight, and low profile, it provides high data security, making installation convenient. With a high IP67 protection rating, this antenna is widely used in logistics and storage management, access control channel management, production line management, material management, etc.
As a leading RFID hardware manufacturer for over a decade, we are committed to delivering unparalleled quality at competitive prices. Our advanced production facilities and stringent quality control ensure that every product meets the highest standards.
EXPERTISE & INNOVATION
Our expert team drives innovation in RFID technology. Whether you need custom solutions or cutting-edge products, we provide advanced and effective RFID solutions tailored to your needs.
EFFICIENT & RELIABILITY
We offer reliable global shipping with in-stock items delivered within 1-3 business days in North America, Europe, and the Asia Pacific. Our proven track record ensures your satisfaction every time.
UHF 5-dBi RFID Antenna ISO 18000-6C
$69.00
The UHF RFID Antenna 5dBi features a high front-to-back ratio, narrow sidelobes, and a 5dBi gain, ensuring stable performance. It enables accurate and rapid multi-label reading and writing, with a moderate read-write distance. Despite its small size, lightweight, and low profile, it provides high data security, making installation convenient. With a high IP67 protection rating, this antenna is widely used in logistics and storage management, access control channel management, production line management, material management, etc.
Description
Features
Frequency Band
UHF 860~960 MHz
International Standard
ISO/IEC 18000-6C, EPC Class 1 Gen2
IP Rating
IP67
Gain Values
5 dBi
Wind resistance
60 m/s
Installation method
Pole-mounting or wall-mounted
Specifications
Physical Specifications
Dimensions: 145x145x20 mm
Weight: 0.73 kg
Shell material: ABS
Radiation plate material: Aluminum
Interface Form: SMA female
IP rating: IP67
Environmental Spec
Operating Limits: -40°C ~ 60°C, DC grounding
Wind Resistance: 60 m/s
Technical Parameters
Frequency: 865~868 MHz | 902~928 MHz
Protocol: ISO/IEC18000-6C, EPC Class 1 Gen2
Horizontal Angle: 80°
Vertical Angle: 70°
Polarization: Circular Polarization (right-handed)
Standing Wave Ratio: ≤ 1.3
Gain Values: 5 dBi
Antenna front-to-back ratio: ≥ 17 dB
Characteristic impedance: 50Ω
Maximum input power: 20W
Installation
Installation: Pole-mounting or wall-mounted
Diameter of support rod: 30-50 mm
Reading Range H-side
Reading Range E-side
RFID Readers to Match ISO 18000-6C Compliant
UHF RFID 4-Port | 8-Port Reader AZF-M1
Cables to Connect 5m for 5 dBi
5-Meter Cable for UHF RFID Fixed Reader AZF-M1
